Wagner Intercooler Megane 4 RS

EXPLORE THE FULL POWER OF YOUR RENAULT MEGANE 4 R.S. (Trophy) WITH THE Wagner Tuning COMPETITION CHARGE AIR COOLER KIT!

Advantages of the Wagner Tuning charge air cooler:
- improved cooling capacity
- 79% external net volume
- Weight 8,1Kg
- Optimized air flow
- Inlet diameter: Ø64mm (like OEM) and outlet diameter: Ø60mm (like OEM)
- Plug & play

Your Renault Megane 4 R.S. (Trophy) deserves the best - and that's exactly what the Wagner Tuning high-performance charge air cooler offers. Featuring a revolutionary Competition core (Tube Fin), this intercooler offers a dimension of performance and efficiency that will impress you. The dimensions of 315 mm x 227 [142] mm x 165 [150] mm [stepped] result in a generous external intercooler core volume of 11.4 liters. Result? A 6% larger frontal flow area and a whopping 47% more external intercooler core volume compared to the stock intercooler. Engineering for maximum performance! Our cast aluminium end boxes were precisely designed in CAD and perfected through CFD simulations with optimal internal airflow. The result? Outstanding cooling performance with minimal back pressure. This kit was designed specifically for racing to ensure optimal cooling of charged air and a significant increase in performance.

Maximum protection and easy installation! Our charge air coolers feature an anti-corrosion coating that not only protects against environmental influences, but also has excellent heat conduction properties. This means a long-lasting and optimal cooling effect, which guarantees the full performance of your vehicle. Installation is carried out at the original mounting points and is child's play thanks to the plug and play principle. Quality is our top priority - all our products are subject to constant qualitative monitoring.

Rely on performance and quality! Your Renault Megane 4 R.S. (Trophy) deserves only the best, and with the Wagner Tuning Competition Intercooler Kit you can achieve just that Unleash the power!

Inlet diameter: Ø65 mm/2,56 Inch ; Outlet diameter Ø67,2 mm/2,64 Inch (stock click-connection)

core dimensions stock intercooler:
290 mm x 233 mm x 115 mm / 11,4 Inch x 9,2 Inch x 4,5 Inch
V = 7,77 L / 474 Inch³
A = 675 cm² / 104,6 Inch²

core dimensions Wagner Tuning intercooler:
315 mm x 227 [142] mm x 165 [150] mm [stepped] / 12,4 Inch x 8,9 [5,6] Inch x 6,4 [5,9] Inch [stepped]
V = 11,4 L / 696 Inch³
A = 715 cm²/ 110,8 Inch²

Part number 200001145:
kit comes with:
1 intercooler
1 silicone hose (black)
1 mounting material
1 installation instruction
